Automatic Sealing Machine
Item Code : S0010
Description:
An automatic sealing machine is designed to create airtight seals on packaging materials such as bags, pouches, or containers. The process typically involves feeding the material, sealing the edges using heat and/or pressure, and in some cases, trimming excess material. The system operates in accordance with standard injection moulding processes, using an injection mold.
The controller and display function independently to ensure high reliability. Its logically structured interface and clearly defined functions make the machine easy, user-friendly, and efficient to operate. A screen saver function helps extend the life of the LCD display.
The display is designed with intuitive indicators to assist with both operation and maintenance. A hardware interlock system is in place to protect against unauthorized access or modifications to molding parameters, preserving machine performance.
The machine features a closed-loop barrel temperature control system, ensuring precise and consistent temperature regulation up to 999°C.
All electrical control components are neatly arranged, securely connected, and housed within dustproof and waterproof electrical cabinets, providing safety and durability in demanding industrial environments.
- Reliable seal, saves time and labour.
- Energy saving variable displacement geared motor for extruder.
- Nozzle pin provided to prevent dryness of material in injection.
- Manual buttons provided to operate manually.
- PLC & control panel in dust proof BCH cabinet.
- Emergency stop button.
- Geared type motor enables high torque and excellent performance.
- The Electronics circuits fully protected and unaffected by dusty environment.
- Digital Display of Temperature & control.
- Machine can move left & right to adjust as per bag width.
- Mounted on wheels for easy mobility.
| Control | PLC |
| Process | Mould closing-material injection-cooling-seal ejection |
| Threaded seal size | Dia 14mm,thick 5mm |
| Provision of Mark | On both sides of plastic seal |
| Temp. controller | Digital to set plastic material temperature. |
| Portability | Mounted on four wheels |
| Capacity | 180-200 bags/hour & more |
| Overall dimension | 1333 x 610 x 1755mm (W x L x H) (approx ). |
| Gross weight | 260 kg |
| Electrical drive | 0.7KW. 440 v 50 Hz, AC |
| Power consumption | 2.3KW |
| Plastic Seal | PP |
| Monogram | Monogram of department |
| Power Supply | 440V Three Phase |
